Teraflex 70" CRD60 HD Rear Full-Float Axle Assembly with 8x6.5 Bolt Pattern for 18-24 Jeep Wrangler JL w/ 0-6" LIft
CRD60 Wide Axle Housing Specifications:
- Axle Diameter - 3.25" O.D. x 0.375" wall DOM axle tube for superior strength vs. weight
- Bolt Pattern -70" WMS-WMS and 8x6.5" wheel bolt pattern
- Proper Pinion Angle and Raised Track Bar Bracket- for lifted JL Applications
- Lift Height - 0 to 6 inches
- Pinion Yoke - 1350 series
- Axle Spline - 35 spline inner & outer
- Oversized outer pinion bearing handles increased torque and high-load conditions
- Reinforced Rear Track Bar Mount-Includes multiple mounting locations
- High-Capacity Housing- Holds maximum amount of oil
- Made in the USA
Heavy-Duty CRD60 Housing: Built to withstand extreme off-road conditions, the CRD60 housing offers superior strength and rigidity. The 3.5" axle tubes are crafted from high-quality steel to reduce flex under load, helping to protect vital components and extend axle life.
Full-Float Design: The full-float construction distributes the weight to the axle housing rather than the axle shafts, enhancing the vehicle’s load capacity and ensuring even weight distribution across the wheels. This design provides a higher degree of stability and makes wheel removal much easier for maintenance.
70" Wide Track: With a 70" wide track, this rear axle provides enhanced stability and increased traction on and off the road. The wider stance improves handling, especially during cornering or when navigating tough off-road trails.
Performance-Driven Gear Ratio: Optimized for Jeeps with up to a 6" lift, the CRD60 axle enables a balanced gear ratio that supports larger tires, maximizing traction and delivering smooth, controlled power for all terrains.
| Product Name | Teraflex 70" CRD60 HD Rear Full-Float Axle Assembly with 8x6.5 Bolt Pattern for 18-24 Jeep Wrangler JL w/ 0-6" LIft |
|---|---|
| Dropdown Labels | Without Ring & Pinion or Choose Gear Ratio |
| Hazmat | No |
| Item Returns | This item can be returned |
