TERA 44 FR AXLE ASSY 4-6IN 4.10 JK RUB

$4,794.99
In stock
SKU
52447-1930

Tera44 Rubicon Axle Assembly Specifications:

  • Axle Diameter - 3.25" OD
  • Axle Tube Thickness - .5" wall
  • Bolt Pattern - 5x5"
  • Axle Width - 67" (factory width)
  • Lift Height - 4 to 6 inches
  • Locker - Factory OEM Rubicon Locker
  • Ball Joints - Teraflex HD ball joints
  • Spicer ring/pinion, bearings & install kits
  • Yoke - Factory style
  • Forged HD inner knuckles
  • Integrated lower control arm skid plates
  • Shipping Dims - 61" x 23" x 20"
  • Shipping Weight - 245 lbs
  • Made in the USA

The TeraFlex Heavy-Duty Front Tera44 R44 Axle Assembly for JK Wrangler & Rubicon with 4-6" of lift is the perfect Replacement Axle Housing for replacing bent, broken, or damaged front axles in JK Wrangler and Rubicon vehicles. This Tera44 Axle Assembly Can also be used as a direct bolt-on upgrade for JK Wrangler owners looking to beef up the front axle’s weak areas. TeraFlex JK Front Tera44 R44 Rubicon Replacement Axle Housings include a heavy-duty housing with axle tubes, bracketry, and forged inner knuckles, pre-installed inner seals and upper control arm bushings as well as OEM Rubicon locker, choice of Spicer ring & pinion gear ratio, Spicer bearings and install kits, TeraFlex heavy-duty ball joints, and a factory yoke. Installation requires that you simply swap over axle shafts, outer knuckles, outer axle assembly, unit bearings, brakes and sensors. The comprehensive assembly makes swapping axle housings a true Do-it-yourself process!

Please Note: This axle assembly requires you to swap over and re-use the original axle shafts, outer knuckles, outer axle assembly, unit bearings, brakes and sensors. (Assembly includes pre-installed inner axle seals)

More Information
Manufacturers Part Number 3545341
Product Name TERA 44 FR AXLE ASSY 4-6IN 4.10 JK RUB
Dropdown Value 1 4.10 Gear Ratio
Prop 65 Message This product can expose you to chemicals including chromium (hexavalent compounds), which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.p65warnings.ca.gov
Length 61
Width 23
Depth 20
Weight 245.000000
Hazmat No
Axle Model Tera44
Axle Position Front
Brand Teraflex
Color Black
Features Electric Locker
Included Parts
  • Axle Assembly Includes:
  • OEM Rubicon locker
  • Spicer ring & pinion
  • Spicer bearings & install kits
  • TeraFlex HD ball joints
  • Factory yoke
Item Returns This item can be returned
