TERA CRD60 RR WIDFLTLCG EMPTY 8X6.5 TJ
$5,658.99
In stock
SKU
52447-1149
CRD60 Wide w/Truss Axle Assembly Specifications:
- Axle Diameter - 3.25" OD
- Axle Tube Thickness - .375" wall
- Bolt Pattern - 8x6.5"
- Axle Width - 67" (extra wide)
- Lift Height - 0 to 6 inches
- Pinion Yoke - 1350 series
- Axle Spline - 35 spline inner & outer
- Brakes - Big Rotor Kit w/ 13.5” rotors
- Shipping Dims - 88" x 25" x 24"
- Shipping Weight - 536 lbs
- Made in the USA
Pro LCG 4-Link Axle Truss: Engineered from CNC laser cut 1/4" steel, precision bent and stitch welded for ultimate strength. Designed to work with the Teraflex Pro LCG suspension system that has a 4-link triangulation. This system eliminates the need for a rear track bar. The rear upper truss bracket features adjustable anti-squat tuning for your suspension. Giving ultimate rock crawling articulation and high speed off-road agility.
The TeraFlex Rear Wide CRD60 Full-Float Axle Housing with Pro LCG Truss is a direct bolt-on upgrade for TJ Wrangler owners looking to replacing weakened, strained, or damaged stock rear axle in TJ Wrangler and Rubicon vehicles. The Extreme-Duty TeraFlex TJ Wide Rear CRD60 Full-Float Axle Housing provides the maximum protection, performance, and durability for the TJ Wrangler, while the exclusive Constant Radius Design (CRD) provides high ground clearance that is unaffected by pinion angle adjustments. The CRD60 Full-float axle design and 8x6.5” wheel bolt pattern is constructed to conquer the utmost Off-Road conditions. The CRD60 Axle is equipped with features that include a heavy-duty housing with heavy-duty axle tubes and bearing caps, high-flow oil passages, bracketry, seamless lines, and increased cover mounting area. Pre-installed seals and upper control arm bushings make the upgrade perfectly consistent. This CRD60 Axle is Compatible with all Super 60 gear ratios for extreme duty applications requiring additional ring and pinion strength.
Please Note:
*** This axle assembly requires a new driveshaft or driveshaft modification. *** The bolt pattern is 8x6.5 which is different from the factory original 5x4.5 bolt pattern. New wheels will be required.
| Manufacturers Part Number | 3980000 |
|---|---|
| Product Name | TERA CRD60 RR WIDFLTLCG EMPTY 8X6.5 TJ |
| Prop 65 Message | This product can expose you to chemicals including chromium (hexavalent compounds), which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.p65warnings.ca.gov |
| Length | 88 |
| Width | 25 |
| Depth | 24 |
| Weight | 536.000000 |
| Hazmat | No |
| Axle Model | CRD60 |
| Axle Position | Rear |
| Brand | Teraflex |
| Color | Black |
| Features | With Brakes, With Differential Cover |
| Included Parts | Axle Assembly |
| Item Returns | This item can be returned |
