ROCKHARD PATRIOT TUBE SLIDER W/STEP JK

Functional Design: These bolt on just like your Rubicon sliders but give you much more capability both on and off the trial. Each mounting bar is 2" x 3" .120 thick steel making them indestructible rock crushers. They are set in a jig and weld on 1 3/4" .120 tubing giving you a step you don't know how you lived without. The tube also helps keep your Jeep off the rocks by giving you a steel "cushion" that takes all the abuse the trail can throw at them. Each slider's end cap is welded shut to prevent debris, water, and dirt from getting inside.

Ease of Installation: The mounting bar that secures Rock Hard's Tubular Rocker Guards to your body perfectly contours to the curves of your JK. This means a rock solid mounting surface and properly distributed weight load when your slider is being put to use. Put those drills away - no drilling required! This replaces your Rubicon rail completely so you can mount in more places along your Jeep's body.

Commonly Asked Dimensions:

• Door outwards to top of rail: 4" (step out distance)
• Distance from bottom of door cutout to top of rail: 3.5" (step down distance)
• Distance from rectangular rail to top of tube: 0" (distance rail sticks up from top of rail)
• Longer bolt size: 12mm x 1.75 (1-3/4") x 120mm
